Rapid Check flowmeter 10-100 l/min
Turbine, 10-100 l / min, Tecomec / Arag flange connection.
In stock
Bertolini pumps of the Poly 2020 series are protected against all corrosive substances and are perfectly suited for lime bleaching.
| Manufacturer: | Bertolini |
|---|---|
| Catalog number: | Poly 2020 RTE |
| Pump type: | Diaphragm | |
| Number of piston: | 2 | |
| Pump capacity: | 22 l/min | |
| Maximum pressure: | 15 Bar | |
| Power: | 230 V AC | |
| Pressure regulator: | YES | |
| By-Pass valve: | YES | |
| Metal elements: | AISI 316 Inox | |
| Screws: | Dacromet technology | |
| Diaphragm: | Rubber | |
| Maximum rotation: | 650 rpm | |
| Maximum power: | 1.1 HP (0.8 kW) | |
| Negative pressure: | 1 m | |
| Suction hosetail: | 20 mm | |
| Pressure hosetail: | 8 mm" | |
| Maximum working temperature: | 60 °C | |
| Oil type: | SAE 30 | |
| Oil quantity: | 0.7 l | |
Show more
